IAG V3 Top Feed Fuel Rails | 2002-2014 Subaru WRX, 2007-2021 Subaru WRX STI, and 2008-2012 Subaru Legacy GT (IAG-AFD-2102)

V3 Top Feed Fuel Rails from IAG Performance

The IAG Performance V3 Top Feed Billet Aluminum Fuel Rails with phenolic spacers are designed to increase the power ceiling on your Subaru’s fuel system. The factory fuel rails function in a series, which means that each cylinder’s fuel is delivered after the other. As horsepower rises past the 350whp mark, the stock rail often does not have the capacity to deliver fuel to the last cylinder effectively*. As a result, that last cylinder can run lean, which can result in catastrophic failure.

The IAG billet fuel rails are designed to eliminate this problem. First, our fuel rails operate in parallel format, each cylinder bank receives equal fuel, matching the flow between the rails ensures that each injector sees the same fuel pressure. Second, the bore of our rail is machined to 5/8″ ID and is designed to accept -8 O-ring boss fittings. This configuration greatly increases the volume of the rail which means that more fuel is available at higher power levels and IAG’s fuel rails were real-world tested to 1000hp.

The IAG V3 fuel rails also feature a port to add an optional fuel pressure pulsation damper between each pair of injectors. Fuel dampers absorb fuel oscillations caused by injectors opening and closing. All Subarus are equipped with a fuel damper however its location is some distance from the injectors. The IAG V3 rails locate the damper between the injectors to help maintain constant pressure. Finally, the IAG V3 fuel rails add phenolic spacers that are located between the rails and the TGV’s. The phenolic spacers aid in reducing heat transferring from the engine to the fuel entering the engine. The included spacers come in two sizes to accommodate the fitment of various fuel injectors.

Features

• CNC machined billet aluminum construction
• 5/8 Bore I.D. designed to accept -8 O-ring boss fittings
• 2 piece mounting design (Phenolic Thermo Spacers)
• Recessed mounting hardware
• Integrated port for fuel damper between injectors
• Engraved with IAG Logo

Applications

• 2002 – 2014 Subaru Impreza WRX
• 2007 – 2014 Subaru Impreza WRX STi
• 2015 – 2021 Subaru WRX STI
• 2008 – 2012 Subaru Legacy GT
• 2006 – 2013 Subaru Forester XT

What’s In The Box?

• 2 – Billet Fuel Rail
• 4 – Zinc coated socket head cap bolt
• 4 – Phenolic Short Spacers
• 4 – Phenolic Long Spacers
• 4 – O-rings
• 2 – Hex Head Threaded Plugs

Warranty

• Manufacturer’s Warranty
