Boomba Racing 75mm DBW Snap-On Throttle Body | 2004-2014 Subaru STi (001-00-019)

04-14 Subaru STi 75mm DBW Snap-On Throttle Body by Boomba Racing

WRX / STI 75 MM Drive By Wire Throttle Body is a direct replacement of the factory unit. The throttle body is designed in such way that it will have to use stock TPS and servo motor.

It fits 2004.5-2014 STI models with drive by wire TB. Our 75 MM throttle body comes as a kit including stock manifold adaptor plate and 60 MM hose adaptor (for those that want to use it immediately with stock intake pipes). The kit also includes 75 MM hose adaptor and all mounting hardware. Throttle bodies are CNC machined of billet aluminum.

Increasing the diameter to 75 MM gives almost 56% increase in throttle cross section area over the stock throttle body. Replacing stock throttle body with our new 75 MM (even with stock pipes and turbo) will give you a few additional HPs and greatly improve engine response. Replacing the stock throttle body with our 75 MM throttle body and replacing intake piping with larger diameter (75 MM) gives limitless possibilities of increasing engine power.

Features

• Premium CNC machined billet aluminum, anodized
• Includes stock manifold adapterplate
• Includes 60 mm and 75 mmhose adapters
• 75mm bore is 56% larger thanstock
• A must-have for any high HP build
• Includes all mounting hardware

Please Note: This Throttle Body will only accept stock TPS cover and servo motor from factory SNAP ON unit.

Applications

• 2004 – 2014 Subaru STi*
• *Models with DBW Throttle Body

Benefits

• Adds Horsepower and Torque
• Greatly Improves Engine Response

What’s In The Box?

• 1 – 75mm DBW Throttle Body
• 1 – Stock Manifold Adapter Plate
• 1 – 60mm Hose Adapter
• 1 – 75mm Hose Adapter
• Necessary Hardware

References

• Installation Instructions

Warranty

• Boomba Racing Limited Warranty
